Carmix 25FX

Carmix 25FX

Small Concrete Mixer 4x4

The Carmix 25FX has a concrete yield of 2.5m³ per batch.

The fixed drum has a 3450 litre capacity and is fitted with double mixing screws, while the drum’s rotation is controlled by a hydraulic motor which controls the mixing and discharging speed.

The Carmix 25FX boom is equipped with a self-articulated hydraulically operated 400 litre shovel with opening gate that allows efficient loading of aggregates and cement. Additionally the Carmix 25FX has two 275 litre tanks with a water pump capable of pumping 400 litres per minute.

The Carmix 25FX has an operating speed of 0-10km/h, road transfer speed from 0-24km/h and is capable of operating on gradients of up 30° fully loaded.
25FX

Carmix 25FX is ideal for

Construction companies producing volumetric batches of concrete for a variety of applications which include but not limited to floor slabs, mortar, plaster as well as fine aggregate concretes.
